The skid steer loader is a wheeled special chassis equipment that uses the difference in linear speed of the wheels on both sides to achieve vehicle steering. It is mainly used in situations where the work site is small, the ground is undulating and the work content changes frequently.
Model :
LT45Load Capacity :
700kgOperating Weight :
2700kgBucket Capacity :
0.4m³ODM/OEM :
SUPPORT
700kg skid steer loader characteristics
1.The hydraulic quick-change couplings are the same as the BOBCAT and are suitable for our skid steer attachments as well as foreign attachments.
2.Manual operation: Hand control of travel and work equipment: forward, reverse, turn, lift arm and tilt bucket.
3. Open cabin: with shock absorbing seats, safety rails, removable rear windows
700kg skid steer loader Product Parameters
| Model | LT45 |
| perating load (kg) | 700 |
| Max Speed (km/h) | 12 |
| Rated flux (Lmin) | 62.5 |
| Tire (track)model | 10-16.5 |
| Engin | Xinchai |
| Engin power | 37kw |
| Rated power (Kw) | 37 |
| Fuel tank capacity (L) | 70 |
| Dead weight(kg) | 3000 |
| Self weight buckat(kg) | 2700 |
| Bucket capacity (m3) | 0.4 |
| Overall operating height (mm) | 3980 |
| Height to top of cab (mm) | 2140 |
| Without bucket length (mm) | 2640 |
| Overall length with bucket(mm) | 3420 |
| Dumping height(mm) | 2380 |
| width(mm) | 1720 |
| Bucket width (mm) | 1740 |
| Height to bottom of level bucket(mm) | 2913 |
| Dumping angle at maximum height(" ) | 40 |
| Height to bucket hinge pin (mm) | 3080 |
| Dumping reach(mm) | 700 |
| Rollback o bucket on ground(R) | 30 |
| Rollback of bucket at full height(R) | 104 |
| wheelbase(mm) | 991 |
| Ground clearance(mm) | 185 |
| Angle of departure(°) | 20 |
| Front turning radius without bucket(mm) | 1168 |
| Front tuning radius(mm) | 1958 |
| Rear tuning radius(mm) | 1728 |
| Rear axle to bumper (mm) | 1208 |
| Tread width (mm) | 1500 |
With technological innovation, our product configuration and parameters will continue to change without notice
If there is any doubt, the specific confirmation of our international trade sales shall prevail
FAQ about 700kg Wheel Skid Steer Loader
1.Why choose us?
LTMG Machinery Group has been operating in the skid steer loader industry for more than 15 years, LTMG has rich experience in manufacturing, sales and after sales service of skid steer loaders.
2.What certificates do we have?
All skid steer loaders meet the requirements of ISO9001 quality system and have obtained CE certificate. We can also cooperate with our customers to get the unique certificate of their countries.
3.Can we provide OEM service?
LTMG industrial can provide customized skid steer loader according to customers' requirements,both OEM and ODM are acceptable.
4.How long is the warranty?
The warranty for LTMG skid steer loaders is 1 year or 2000 working hours, whichever comes first.
5.What is our delivery time?
It usually takes 15 to 30 days after receiving your deposit. Regarding standard products, we
always have in stock for immediate delivery. However, custom products will take more time depending on your order requirements.
