Skid steer loaders are also known as multifunctional construction vehicles and multifunctional construction machines. It is suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residences, barns, livestock barns, airport runways, etc. It can also be used as auxiliary equipment for large engineering construction machinery.
Model :
LT65Load Capacity :
950kgOperating Weight :
3400kgBucket Capacity :
0.5m³ODM/OEM :
SUPPORT
Wheel Skid Steer Loader Product characteristics
1.Fully enclosed cab, both doors with tempered glass, side windows can be easily opened and closed. The front door is equipped with door lock and wiper, according to user requirements, it can be equipped with heating and cooling air conditioner or heater.
2.Dual throttle control mode: manual + foot-activated for ease of use.
3.Equipped with an oversized radiator and fuel tank for continuous operation in the tropics.
Wheel Skid Steer Loader Product parameters
| Model | LT65 |
| perating load (kg) | 950 |
| Max Speed (km/h) | 12 |
| Rated flux (Lmin) | 75 |
| Tire (track)model | 12-16.5 |
| Engin | Xinchai |
| Engin power | 45kw |
| Rated power (Kw) | 45 |
| Fuel tank capacity (L) | 80 |
| Dead weight(kg) | 3400 |
| Self weight buckat(kg) | 3400 |
| Bucket capacity (m3) | 0.5 |
| Overall operating height (mm) | 4070 |
| Height to top of cab (mm) | 2160 |
| Without bucket length (mm) | 2880 |
| Overall length with bucket(mm) | 3580 |
| Dumping height(mm) | 2450 |
| Width(mm) | 1880 |
| Bucket width (mm) | 1880 |
| Height to bottom of level bucket(mm) | 2983 |
| Dumping angle at maximum height(" ) | 40 |
| Height to bucket hinge pin (mm) | 3150 |
| Dumping reach(mm) | 700 |
| Rollback o bucket on ground(R) | 30 |
| Rollback of bucket at full height(R) | 104 |
| wheelbase(mm) | 1115 |
| Ground clearance(mm) | 205 |
| Angle of departure(°) | 20 |
| Front turning radius without bucket(mm) | 1250 |
| Front tuning radius(mm) | 2112 |
| Rear tuning radius(mm) | 1774 |
| Rear axle to bumper (mm) | 1082 |
| Tread width (mm) | 1500 |
With technological innovation, our product configuration and parameters will continue to change without notice
If there is any doubt, the specific confirmation of our international trade sales shall prevail
FAQ about Wheel Skid Steer Loader
1.How long is the Warranty for LTMG skid steer loader?
LTMG provides 12 months or 2000 working hours,whichever occurs first.
2.How about the delivery time of LTMG skid steer loader?
For some standard products, we may have stock and could delivery immediately. If there is no stock, usually LTMG producing time is 15-30 working days from the date advanced payment received.
3.Can LTMG provide customized products? OEM products or ODM products?
Yes, LTMG can provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products.
4.Could we request our own color for the skid steer loader?
Yes, of course, you just need to offer us the RAL code.
