950kg 1 ton Wheel Skid Steer Loader With Strong Engine
950kg 1 ton Wheel Skid Steer Loader With Strong Engine
950kg 1 ton Wheel Skid Steer Loader With Strong Engine
950kg 1 ton Wheel Skid Steer Loader With Strong Engine

950kg 1 ton Wheel Skid Steer Loader With Strong Engine

Skid steer loaders are also known as multifunctional construction vehicles and multifunctional construction machines. It is suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residences, barns, livestock barns, airport runways, etc. It can also be used as auxiliary equipment for large engineering construction machinery.

  • Model :

    LT65
  • Load Capacity :

    950kg
  • Operating Weight :

    3400kg
  • Bucket Capacity :

    0.5m³
  • ODM/OEM :

    SUPPORT
  • Share to :
  • Youtube
  • Facebook
  • Instagram
  • linkedin
  • twitter
wheel tyre skid steer loader

Wheel Skid Steer Loader  Product characteristics

1.Fully enclosed cab, both doors with tempered glass, side windows can be easily opened and closed. The front door is equipped with door lock and wiper, according to user requirements, it can be equipped with heating and cooling air conditioner or heater.

2.Dual throttle control mode: manual + foot-activated for ease of use.

3.Equipped with an oversized radiator and fuel tank for continuous operation in the tropics.

Wheel Skid Steer Loader  Product parameters

Model LT65
perating load (kg) 950
Max Speed (km/h) 12
Rated flux (Lmin) 75
Tire (track)model 12-16.5
Engin Xinchai
Engin power 45kw
Rated power (Kw) 45
Fuel tank capacity (L) 80
Dead weight(kg) 3400
Self weight buckat(kg) 3400
Bucket capacity (m3) 0.5
Overall operating height (mm) 4070
Height to top of cab (mm) 2160
Without bucket length (mm) 2880
Overall length with bucket(mm) 3580
Dumping height(mm) 2450
Width(mm) 1880
Bucket width (mm) 1880
Height to bottom of level bucket(mm) 2983
Dumping angle at maximum height(" ) 40
Height to bucket hinge pin (mm) 3150
Dumping reach(mm) 700
Rollback o bucket on ground(R) 30
Rollback of bucket at full height(R) 104
wheelbase(mm) 1115
Ground clearance(mm) 205
Angle of departure(°) 20
Front turning radius without bucket(mm) 1250
Front tuning radius(mm) 2112
Rear tuning radius(mm) 1774
Rear axle to bumper (mm) 1082
Tread width (mm) 1500

With technological innovation, our product configuration and parameters will continue to change without notice

If there is any doubt, the specific confirmation of our international trade sales shall prevail



FAQ about Wheel Skid Steer Loader

1.How long is the Warranty for LTMG skid steer loader?

LTMG provides 12 months or 2000 working hours,whichever occurs first.



2.How about the delivery time of LTMG  skid steer loader?

For some standard products, we may have stock and could delivery immediately. If there is no stock, usually LTMG  producing time is 15-30 working days from the date advanced payment received.



3.Can LTMG provide customized products? OEM products or ODM products?

Yes, LTMG can provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products.



4.Could we request our own color for the skid steer loader?

Yes, of course, you just need to offer us the RAL code.
