Searching for a machine that can load, mix, and transport concrete directly at your construction site? The self loading concrete mixer truck will satisfy you needs. Features include left front driving synchronous steering and two-way driving, hydraulic transmission, vacuum dual row tires, and a luxurious integrated cabin, offering enhanced maneuverability, convenience, cost savings, and productivity in construction projects.
Model :
LTM40AWeight :
9,000 KGODM/OEM :
ProvidedLength, width, height :
7600mm * 2950mm * 3400mm
The Features Of The Self Loading Concrete Mixer Truck
Equipped with Turbocharged Engine: Power and reliability converge with the inclusion of the Chinese famous Yuchai turbocharged engine, ensuring robust performance and enhanced fuel efficiency even in the most demanding work environments.
Hydraulic Transmission and Plunger Motor: Experience seamless operation and precise control with the fully hydraulic transmission system and plunger motor, enabling smooth transitions and optimal power distribution throughout the mixing process.
Vacuum Dual Row Tires: Designed for enhanced traction and stability, the vacuum dual row tires provide superior grip on various terrains, ensuring steady maneuverability and minimized slippage for maximum productivity.
Luxurious Integrated Cabin: Step into the epitome of comfort and convenience with our deluxe integrated cabin, featuring ergonomic design elements, ample space, and advanced amenities for the operator's comfort and convenience during long hours on the job.
Optional Accessories: Tailor your mixer truck to suit your specific needs with a range of optional accessories including electronic measurement weighing system, cement hopper, air conditioning, and more, allowing for customization to optimize efficiency and workflow in accordance with your project requirements.
Features include left front driving synchronous steering and two-way driving for enhanced maneuverability,
The Specification Of The Self Loading Concrete Mixer Truck
| Model | LTM40A |
| Output Per Lot | 4.0 cubic metres |
| Drum Rotation | Discharge Port Height 2 meters, cab and tank horizontal rotation 270 tank can be raised and lowered |
| Capacity | Up to 4.5 batches per hour, 18 cubic hours |
| Engine | Yuchai power ycd4j22t 125, diesel, water-cooled, 4 cylinders, 2600 RPM, rated power 91KW |
| Drive Mode | The engine is directly connected to the 280 split Torque converter, and is connected to the gearbox with double high and low speed through the transmission shaft to realize four-wheel drive |
| Climb | 40° |
| Speed | Dual altitude, low speed 0-25kph, high speed 0-40 kph |
| Driver'S Seat | Widen the luxurious cab of the excavator, front window can be opened, anti-roll, anti-falling object type, double armrest cushion seat |
| Hydraulic System | Open oil inlet, axial piston motor, two gear pumps to participate in the work |
| Joystick | Two hydraulic pilot joysticks control the scoop, upper arm, 270 turn, lift tank |
| Bucket | 0.7 cubic, hydraulic gate |
| Clay Groove | Equipped with two 150CM Removable Chute to increase the length of discharge |
| Water Supply System | Self-priming driven pump, 24V self-timing Centrifugal pump, car washing machine |
| Braking | Use Small Servo pump on independent double circuit, use single wheel 4-piston plus double brake caliper |
| Steering | Hydraulic articulated steering |
| Tire | 12R-22.5 steel wire high pressure vacuum tire |
| Power System | 24V |
| Fuel Tank / Water Tank | 1 * 800 litres water tank, 135 litres diesel fuel tank, 135 litres hydraulic fuel tank |
| Weight | 9,000 kg |
| Length, Width, Height / Wheelbase / Wheelbase | 7600mm * 2950mm * 3400mm * 3000mm * 2150mm |
| Turning Radius | 3000mm |
| Other | Q345 manganese steel frame, excavator luxury cab, driving video, cement bucket, air conditioning |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
More About LTMG Machinery Co., Ltd.
FAQ
Q: What features should I look for in a self-loading concrete mixer truck?
A: Key features to consider include the engine power, transmission system, tire design for stability, cabin comfort, and optional accessories such as electronic measurement weighing system, cement hopper, and air conditioning.
Q: How does a self-loading concrete mixer truck work?
A: The truck's mixing drum rotates to load raw materials, such as aggregates, cement, and water. It then mixes them thoroughly while in transit to the construction site, and finally, it can discharge the ready-mixed concrete directly onto the desired location.
Q: Can a self-loading concrete mixer truck be used in various construction projects?
A: Yes, self-loading concrete mixer trucks are versatile and can be used in a wide range of construction projects, including residential, commercial, and infrastructure developments.
Q:How can I trust your company?
A:With 22-years-professional manufacture, we can provide you suitable suggestion and lowest price.
