The LTMG T320 crawler bulldozer is fitted with Cummins NT855-C360 turbocharged diesel engine, powerful and performance. Adopted GPRS system, achieve remote monitoring and fault diagnosis to main parameter by network. Widely used in large mines, ports, power plants and highway construction and other work sites.
Model :
T320Engine :
Cummins NTA855-C360S10Operating Weight :
34570 KGPower :
320HP(257kW)ODM/OEM :
SUPPORT
1.Awarded the ISO9001:2000 system certificate.
2.Fitted with highly efficient Cummins NT855-C360 turbocharged diesel engine.
3. Adopted imported famous VDO monitoring instrument, accurate data on various aspects of the machine's perfomance, empowering you to make informed decisions.
4. The seat with automatic angle and height adjusting system provide convenient and flexible operation.
5. Adopted new noise-reducing materials, the crawl bulldozer ensures minimal disruption to your work environment.
6. Boating GPRS technology, you can effortlessly monitor and manage the crawl equipment's performance remorely.
T320 Crawler Bulldozer Equipment Parameters
| Model | T320 | |
| Type | 320HP Standard Hydraulic Crawler Type | |
| Engine | Cummins NTA855-C360S10 | |
| Rated power | kw/rpm | 257 |
| Max.torque | N.m/rpm | 1509/1400 |
| Operating weight |
KG |
35900 |
| Min ground clearance |
mm |
500 |
| Ground pressure |
MPa |
93 |
| Track gauge |
mm |
2140 |
| Blade Capacity |
m³ |
9.96 |
| Blade Width x Height |
mm |
4130 x 1553 |
| Track shoes width | mm | 560 |
| Pitch | mm | 228.6 |
| Quantity of track shoes | 41 x 2 | |
| Quantity of carrier rollers | 2(each side) | |
| Quantity of track rollers |
7(each side) | |
| Working pressure | MPa |
14 |
| System Discharge | L/min |
390 |
| Max. Pulling Force |
KN | 260 |
| Grade ability |
° | 30 |
| Forward speed | km |
1st 0～3.6 |
| 2nd 0～6.6 | ||
| 3rd 0～11.5 | ||
| Reverse speed | km |
1st 0～4.4 |
| 2nd 0～7.8 | ||
| 3rd 0～13.5 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
The Video of the 320HP Crawler Bulldozer
FAQ about the 320HP crawler bulldozer
1. What are the applications of crawler bulldozers?
Bulldozers are widely used in numerous applications, including land clearing, road construction, mining operations, forestry, and landfill management. Their versatility and power enable them to handle various tasks efficiently, making them indispensable in the construction industry.
2. What are the advantages of using a bulldozer?
Using a bulldozer offers several advantages. With their impressive strength and size, bulldozers can navigate through challenging terrains, ensuring effective land leveling and groundwork preparation. Additionally, they significantly enhance productivity, minimize labor requirements, and expedite construction projects.
3. What Certificates do you have?
LTMG meet with the ISO9001:2008 Quality System. All of our products with CE certificate.
