Looking for a powerful workhorse to tackle your mining operations? Discover the capabilities of a mining dump truck! These colossal machines are designed to transport large quantities of materials over rugged terrains with ease. From hauling massive loads of rocks, minerals, and ore to maximizing efficiency and productivity, mining dump trucks are helpful tool of the mining industry.
Model :
LMDT350Engine :
WP12.400E201 Euro IIIOperating Weight :
36000 KGODM/OEM :
Support
Features of Heavy Duty Mining Dump Truck
Equipped with an exceptionally strong and reliable power system, the heavy duty mining dump truck delivers unwavering performance in the toughest terrains. The frame system boasts superior structure, ensuring enhanced and a higher carrying capacity to optimize your hauling capabilities.
Features an advanced suspension system that prioritizes safety and reliability, offering a smooth and stable ride even on uneven surfaces. Whether it's traversing rough terrains or navigating steep inclines, this truck provides unparalleled comfort and stability.
With its cargo boxes constructed from top-quality materials, the truck guarantees exceptional durability and an increased carrying capacity. This means you can transport larger volumes of materials efficiently, streamlining your mining operations and maximizing productivity.
The spacious cab of the dumper truck offers a wide view, facilitating excellent visibility for the operator. This not only enhances safety but also promotes a comfortable driving experience, reducing fatigue during long shifts. After all, we believe that a comfortable and focused operator is key to achieving optimal productivity.
Parameters of Mining Dump Truck
| Model | LMDT350 |
| DIMENSIONS |
|
| Wheelbase (mm) | 3775+1400 |
| Dump body Length (mm) | 5600 |
| Dump body Width (mm) | 2300 |
| Dump body Height (mm) | 1500 |
| Dump body Cubic (m³) | 19.32 |
| Lift Way | Middle Lift |
| Overall Length (mm) | 8600 |
| Overall Width (mm) | 2500 |
| Overall Height (mm) | 3450 |
| WHEELS | |
| Tyre Size | 13R22.5 |
| Type | Tubeless Tire |
| MASS DATA | |
| Curb Vehicle (Kg) | 14000 |
| Gross Vehicle Weight (Kg) | Up to 50000 |
| Max Payload Weight(Kg) | 36000 |
| Front Axle Load Weight (Kg) | 9500 |
| Rear Axle Load Weight (Kg) | 32000 |
| CHASSIS & SUSPENSION | |
| Type | Two Layer (8+8)mm Height 320mm Width 90mm |
| Front Suspension | Semi-Elliptical Leaf Springs |
| Rear Suspension | Semi-Elliptical Leaf Springs |
| CABIN | |
| Cabin | H3000, Flat Cabin, One sleeper |
| Drive | Left Hand Drive |
| Type/Extras | Aircon, Four Point Suspension Max Payload Weight(Kg) 36000 Electrical Window Lifter, Oil Bath Front Axle Load Weight (Kg) 9500 air filter, Two warning light |
| ENGINE | |
| Make & Model | WP12.400E201 |
| Capacity | 11.596 |
| Layout & Type | 6 cylinder in line, intercooler Dump body Length (mm) 5600 manual pump, turbocharger Dump body Width (mm) |
| Emissions Standard | Euro II |
| Max Power (PS) | 400 |
| Max Torque (Nm)@ r/min | 1800/1000-1400 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
FAQ
Q: What is a mining dump truck?
A: A mining dump truck is a specialized heavy-duty vehicle designed for transporting large quantities of materials, such as rocks, debris, or minerals, in mining and construction sites. It is equipped with a hydraulic dumping mechanism to unload the cargo easily.
Q: Are mining dump trucks suitable for all types of mining operations?
A: Mining dump trucks come in various sizes and capacities to cater to different mining operations. Smaller trucks are suitable for smaller mines, while larger trucks are used in open-pit mining or large-scale operations. It is important to select a dump truck model that matches the specific requirements of the mining site.
Q: Can mining dump trucks be used in other industries?
A: While the trucks are primarily designed for mining applications, their robust construction and large load-carrying capacity make them suitable for other industries such as construction, quarrying, and large-scale material transportation.
Q: What is LTMG Machinery Group?
A: LTMG Machinery Group is a professional manufacturer of material handling equipment and construction machinery equipment established in 2001.
Q: Are Your Prices Competitive?
A: We only supply good quality machines. We will surely offer you the best ex-factory price on the basis of high quality products and services.
