LTE275 advanced hydraulic system not only provides the best balance between power and efficiency, but also gives you the controls you need to meet your precise digging requirements.
Model :
LTE275Operating Weight :
27500KGBucket Capacity :
1.3m³ODM/OEM :
SUPPORT
1. High-end first-class core configuration. Equipped with Cummins 169kwkw engine, energy saving and fuel saving.
2. International brand Kawasaki pumps, Inline valves. World brand hydraulic components ensure high reliability of the hydraulic system
3.Higher reliability and durability. Sturdy high-strength fuselage reinforced boom, stick, bucket structural parts.
4. More coordinated comfort. High-rigidity new cab, quiet and comfortable Color LCD monitor, convenient for monitoring and maintenance Multiple operating modes are optional
Techincal Paremeter
| Performance Parameters | Unit | LTE275 |
| Operating Weight | Kg | 27500 |
| Bucket Capacity | m³ | 1.3 |
| Engine Model | Cummins QSB7.0 | |
| Rated Power | Kw | 169/2050 |
| Max Digging Force | Kn | 172 |
| Swing Speed | rpm | 10.5 |
| Traveling Speed | km/h | 4.1/4.2 |
| Gradeability | ° | 70 |
| Average Grounding Pressure | Kpa | 56 |
| MAX. Flow | L/min | 228*2 |
| Setting Pressure | Mpa | 37.3 |
| Volume of Hydraulic Tank | L | 246 |
| Volume of Fuel Tank | 420 | |
| Wroking Range | ||
| Max.Digging Height | mm | 9310 |
| Max.Dumping Height | mm | 6440 |
| Max.Digging Depth | mm | 6875 |
| Max.Vertical Digging Depth | mm | 5860 |
| Min.Swing Radius | mm | 3975 |
| Max. Digging Reach | mm | 10170 |
| Height Of Counterweight | mm | 2165 |
| Overall Dimensions | ||
| Overall Length | mm | 10000 |
| Overall Width | mm | 3190 |
| Overall Height | mm | 3125 |
| Cabin Height | mm | 3220 |
| Wheel(Track) Distance | mm | 2590 |
| Min.Ground Clearance | mm | 520 |
| Tail Swing Radius | mm | 2910 |
| Track Length | mm | 4625 |
| Track Grounding Length | mm | 3715 |
| Track Width | mm | 3190 |
| Arm Length | mm | 3050 |
| Boom Length | mm | 5850 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
FAQ
1. What payment terms can we accept and our delivery time?
T/T; L/C; D/P ; It usually will take 20 days-30 days after receiving your deposit.
2. What Certificates do LTMG have?
LTMG excavator awarded several invention and appearance patents ；All products meet with the ISO9001 Quality System and have acquired CE certificate，guaranteed the product quatity
3.About our machinery parts suppliers？
LTMG's core components are sourced from world renowned suppliers such as Cummins, Rexroth, etc. and are also available in a variety of high performance options to suit different customer needs.
4. Can we provide OEM service?
LTMG industrial can provide customized products according to customers' requirements,both OEM and ODM are acceptable.
5.Our warranty time
From 1 year
