Discover the power of the LTMG mini crawler excavator. Equipped with an imported Japanese engine, versatile standard configuration, and multi-function capabilities, it's the ideal solution for a range of applications, such as tunnel construction, horticulture, municipal engineering and so on.
Model :
LTE15Operating Weight :
1500KGBucket Capacity :
0.025m³ODM/OEM :
Support
Features of 1.5 ton Mini Compact Tracked Excavator
Delivers strong work performance with excellent cost efficiency, ensuring high productivity at a competitive price.
Versatile Standard Configuration
Capable of site leveling and backfilling tasks, enhancing operational stability across various job types.
Compact and Flexible Design
Small, easy to transport, and ideal for confined spaces such as orchards and farms—perfect for trenching, fertilizing, and weeding.
Multi-Functional with Quick Attachments
Supports attachments for mining, crushing, debris removal, and drilling, expanding its utility and adaptability for diverse operations.
| LTE15 Technical Specification | ||
| Engine | ||
| Model | Kubota D722 10.4KW/2500rpm | |
| Max. Turque | 45N.m/2500RPM | |
| Type | In-line, water-cooled, 4-stroke, Mechanical pump, normally aspirated | |
| Displacement | 0.719 | |
| No. of cylinder | 3 | |
| Main Performance | ||
| Swing Speed | r/min | 12-13 |
| Traveling Speed(high/low) | km/H | 2.1/3.2km/h |
| Grade ability | ° | 58% |
| Max. Bucket Digging Force | kN | 9 |
| Arm Digging Force | kN | 5.5 |
| Ground Pressure | Kpa | 23 |
| Hydraulic system pressure | Mpa | 20 |
| Machine Weight | KG | 1400 |
| Fuel Tank capacity | L | 14.5 |
| Hydraulic Tank capacity | L | 14.5 |
| Engine oil capacity | L | 3.2 |
| Overall Dimensions | ||
| Overall Length | mm | 3329 |
| Overall Width | mm | 990 |
| Overall Height | mm | 2267 |
| Mini Ground clearance | mm | 153 |
| Track width | mm | 200 |
| Axle base(Track length on ground) | mm | 1190 |
| Track Gauge | mm | 790(1100) |
| Swing radius at tail | mm | 655 |
| Swing radius at front | mm | 1812 |
| Height of blade | mm | 210 |
| Max. Dozer blade cutting | mm | 229 |
| Max.Dozer blade lifting | mm | 236 |
| Bucket Capacity | m³ | 0.025 |
| Max. Digging Radius | mm | 3529 |
| Max. Digging Depth | mm | 2017 |
| Max. Digging Height | mm | 2955 |
| Max. Dumping Height | mm | 2077 |
| Max. vertical digging depth | mm | 1610 |
With technological innovation, our product configuration and parameters will continue to change without notice.
If there is any doubt, the specific confirmation of our international trade sales shall prevail.
Transportation of Crawler Mini Excavator
Certification of Mini Excavator
More related products
FAQ
Q.There are several reasons why you should choose us:
A: Excellent work efficiency / Excellent cost-effectiveness / Many standard configurations/Versatile and flexible /Multi-functionality with quick accessory
Q.What range of machines does LTMG Industries specialize in?
A. Wheel Loaders / Forklift Trucks / Excavators / Attachments /Customized Products
Q.What payment methods are available to you?
A.30% Deposit, 70% Balance: This is the standard payment term where a 30% deposit is required upfront, and the remaining 70% balance is settled before shipment. 100% Irrevocable L/C at Sight: We also accept 100% irrevocable Letter of Credit (L/C) at sight.
Q.When do you typically get our products?
A. Standard products ship within 15–30 days after deposit. In-stock items can be delivered immediately. Customized orders may take longer depending on specific requirements—we’ll provide an exact timeline based on your needs.
