This 23-ton excavator is equipped with a 1.1 cbm bucket and a 124 kW Cummins QSB7 engine that complies with the EPA emission regulations, providing strong power. Double pump combined flow technology increases the flow of the main valve to each cylinder of the moving arm, bucket rod, and bucket to improve the operating speed.
Model :
LTE230Operating Weight :
23000kgBucket Capacity :
1.1m³ODM/OEM :
SUPPORT

23 Ton Excavator Product Characteristics
1. Environmentally Friendly: Equipped with a highly efficient Cummins engine that meets the EPA emissions standards, the large excavator features with improving fuel efficiency, reduced fuel consumption, and optimized engine performance, contributing to a greener and more sustainable environment
2. Various types of filters are installed in the most suitable locations for one-stop replacement and easy maintenance.
3. Multifunctional LCD monitor with large screen, digital display, comprehensive monitoring of the engine's working status (speed, water temperature, oil pressure, etc.), and various operating information of the machine can be checked at any time.
4. Adapt the GPS satellite positioning system, remote diagnosis, fault warning, maintenance, and automatic reminder.
5. Equipped with comfort and spaciousness, ensuring that the operator can work uninterrupted for long periods of time.
6. The advanced control system makes it easy for operators to maneuver the machine with precision and accuracy.
23 Ton Excavator is a robust piece of machinery that has been specifically designed to make digging and excavation work more efficient and effortless. With its rugged build, advanced features, and user-friendly design, this excavator has been optimized to deliver unparalleled performance and reliability even in the toughest and most demanding construction environments.
Customer Feedback of 23-ton Crawler Excavator
23 Ton Excavator Technical Parameters
| Performance Parameters | Unit | LTE230 |
| Operating Weight | Kg | 23000 |
| Engine Model | Cummins QSB7 | |
| Rated Power | Kw | 124KW/2050rpm |
| Bucket Capacity | m³ | 1.1 |
| Swing Speed | rpm | 0-13 |
| Traveling Speed | km/h | 3.8-4.2 |
| Gradeability | ° | 30° |
| Hydraulic System | ||
| Hydraulic system working pressure | Mpa | 34 |
| Hydraulic Pump | PNM | |
| Hydraulic Valve | Parker | |
| Swing Motor | Strong(Sunjin) | |
| Traveling Motor | Doosan | |
| Operating Range | ||
| Max. Digging Radius | mm | 9936 |
| Max. Digging Depth | mm | 6550 |
| Max. Digging Height | mm | 9680 |
| Max. Dumping Height | mm | 6730 |
| Distance from swing center to tail | mm | 2880 |
| Overall Dimensions | ||
| Overall Length | mm | 9565 |
| Overall Width | mm | 2990 |
| Overall Height | mm | 3000 |
| Track Width | mm | 600 |
| Track Height | mm | 950 |
With technological innovation, our product configuration and parameters will continue to change without notice.
If there is any doubt, the specific confirmation of our international trade sales shall prevail.
Optional Attachments & Shipping Plan
LTMG provides customers with various optional attachments, including but not limited to buckets, rippers, rakers, auger drills, and grippers, which are meticulously designed to cater to diverse and distinct requirements across various working sites.


FAQ about 23 Ton Excavator
1. What payment terms can we accept?
T/T; L/C; D/P
2. What Certificates do we have?
All products meet the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
3. How about our delivery time?
It usually will take 30- 45 days after receiving your deposit.
4. Can we provide OEM service?
LTMG Industrial can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
5. What is LTMG's policy for responding to customer questions and concerns?
LTMG responds to any questions within 24 hours and provides free wearing parts during the warranty period. If you are not satisfied with any details of our company's sales and service, please feel free to contact us and we will do our best to solve your problems in time.
