The 220 HP Heavy Duty Wheel Bulldozer is designed for demanding earthmoving and material-pushing operations in construction, mining, and infrastructure projects. Equipped with a powerful high-torque engine and advanced hydraulic system, this wheel dozer delivers strong pushing force, stable performance, and excellent mobility across various terrains. Compared with traditional crawler bulldozers, wheel bulldozers offer higher travel speed, better maneuverability, and lower ground damage, making them ideal for road construction, site preparation, and municipal engineering.
Model :
TL220Operating Weight :
15500KGPower :
220HPODM/OEM :
Suooprt
220 HP Heavy Duty Wheel Bulldozer
Powerful 220 HP Engine
The machine is equipped with a 220-horsepower engine, delivering strong torque and stable power output. It ensures excellent pushing performance even in heavy-duty working environments.
High-Efficiency Hydraulic System
An advanced hydraulic control system ensures smooth operation, precise blade control, and improved working efficiency during material pushing and leveling tasks.
Strong Traction and Stability
The optimized chassis structure provides excellent stability and traction, enabling the machine to operate efficiently on rough construction sites and uneven ground.
Comfortable Operator Cabin
The spacious cabin is designed for operator comfort and productivity, featuring ergonomic controls, wide visibility, and an optional air-conditioning system.
Durable Structural Design
Key structural components are reinforced to ensure long service life and reliable performance in heavy-duty construction and mining operations.
220 HP Heavy Duty Wheel Bulldozer Specification
|
Parameter Name |
Value |
|
Overall Dimension (mm) |
7100*3600*3450 |
|
Wheelbase (mm) |
3200 |
|
Wheel track (mm) |
2240 |
|
Height of shovel blade (mm) |
1000 |
|
Weight of complete machine (t) |
15.5 |
|
Maximum lift height of the dozer blade |
1060 |
|
Maximum down depth of dozer blade (mm) |
400 |
|
Blade width |
3600mm |
|
Gradability (°) |
25 |
|
Model of the engine |
STEYR WD10G220E22 |
|
Pattern |
Turbocharger, vertical, water-cooled, 4-stroke, direct injection |
|
Rated power |
162kW |
|
Specified rotational speed |
2100r/min |
|
Max. torque |
860N.m |
|
Min. fuel consuming rate |
126g/kWh.h |
|
Total displacement |
9.726L |
|
Fuel |
0# or 10# diesel oil |
|
Model of torque device |
HANGZHOU ADVANCE |
|
Pattern |
3-element, single-stage triple element |
|
Transmission type |
Full-powershift, countershaft type |
|
Number of gear positions |
2 forward, 1 reverse |
|
Max. travel speed |
40km/h |
|
Axle |
Feicheng/Hualu |
|
Main reducer type |
Arc taper gear, model reduction of first grade |
|
Pattern of wheelside moderation |
Single-stage planetary |
|
Tire size |
23.5-25 |
|
Pattern |
Full hydraulic steering system |
|
Min. turning radius (outside of bucket) |
7268mm |
|
Max. turning angle |
35° ±1 |
|
Implement the pump work model |
CBGJ2080/1010 |
|
Displacement |
250L/min |
|
System working pressure |
20.3MPa |
|
Distribution device model |
DF32 |
|
Pilot valve model |
DJ5 |
|
Brake system |
Air-assisted oil disc on four wheels |
|
Parking brake |
Air cutting control inner expand hoof |
With technological innovation, our product configuration and parameters will continue to change without notice. If there is any doubt, the specific confirmation of our international trade sales shall prevail.
Applications of Wheel Bulldozers
Wheel bulldozers are widely used across a variety of industries due to their mobility and high productivity.
Road Construction
Used for grading, leveling, and material pushing during highway and road infrastructure projects.
Mining and Quarry Operations
Suitable for pushing loose materials, clearing working areas, and maintaining mining roads.
Construction Site Preparation
Efficient for land clearing, soil leveling, and foundation preparation before building construction.
Municipal Engineering
Commonly used in urban infrastructure projects such as drainage construction and land development.
Optional Attachments for Wheel Bulldozer
Certified Quality for 220 HP Heavy Duty Wheel Bulldozer
FAQ
A: Wheel bulldozers offer faster travel speed and better maneuverability compared with crawler bulldozers, making them ideal for road construction and urban engineering projects.
A: Wheel bulldozers are widely used in construction, mining, infrastructure development, and land preparation projects.
A: Yes. LTMG provides customized configurations, including attachments, cab options, and working components to meet different project requirements.
A: Yes. We export construction machinery to more than 187 countries and can arrange international shipping and delivery.
